| Approvals/certifications | Certified to EN54-3, 23 & 17 by the LPCB. |
| Protocol/compatibility | Compatible with C-TEC's CAST protocol Addressable Fire Panels. |
| Application/operation | Designed to be wall mounted. Indoor areas only. |
| VAD category & coverage | W-2.75-9 rated light distribution. Also certified as a W-4-4 rated VAD. |
| Flash rate & colour | 0.5Hz / White. |
| Supply/operating voltage | 27 to 40V DC. |
| Quiescent current | 550µA. |
| Nominal SPL (Sound Pressure Level) | 100dB(A) when set to tone 1. |
| Alarm current | 14.5mA (VAD lit, Sounder on max). |
| Indicators | Polling (red LED). |
| Product dimensions (mm) | 108mm diameter x 99mm deep. |
| IP Rating | IP21C (Type A). |
| Weight | 230g. |
| Operating conditions/temperature | -10ºC to +55ºC. Max. 95% RH (Non-condensing). |
