- Equipped with the 32-bit high-speed processor
- RS-485 and Wiegand (W26/W34) protocol, and OSDP protocol
- Build-in Mifare card reading module (Frequency: 13.56 MHz)
- Supports tampering alarm
- Built-in buzzer for identifying the reading status
- Online upgrade function
- Watchdog design for repairing itself in case that exception occurs, to ensure the long service life of the reader
Indicator: Power indicator, status indicator
Power Supply: 12 VDC
Power Consumption: ≤2 W
Working Temperature: -20 °C to 65 °C (-4 °F to 149 °F)
Working Humidity: 10% to 90% (Non-Condensing)
Protective Level: IP65
Dimensions: 115 mm × 44 mm × 22 mm (4.53'' × 1.73'' × 0.87'' )
Installation: Wall Mounting with Screws; Do Not Support Gang Box
Buzzer: Support
| Manufacturer | HIKVISION |
| Credential Type | 13.56MHz |
You will get an e-mail with parcel ID, once the goods are sent out
| up to 5 kg | 3,99 € | up to 10 kg | 5,00 € |
| up to 30 kg | 9,00 € | up to 75 kg | 15,00 € |
| up to 200 kg | 70,00 € | up to 1000 kg | 200,00 € |
- Equipped with the 32-bit high-speed processor
- RS-485 and Wiegand (W26/W34) protocol, and OSDP protocol
- Build-in Mifare card reading module (Frequency: 13.56 MHz)
- Supports tampering alarm
- Built-in buzzer for identifying the reading status
- Online upgrade function
- Watchdog design for repairing itself in case that exception occurs, to ensure the long service life of the reader
Indicator: Power indicator, status indicator
Power Supply: 12 VDC
Power Consumption: ≤2 W
Working Temperature: -20 °C to 65 °C (-4 °F to 149 °F)
Working Humidity: 10% to 90% (Non-Condensing)
Protective Level: IP65
Dimensions: 115 mm × 44 mm × 22 mm (4.53'' × 1.73'' × 0.87'' )
Installation: Wall Mounting with Screws; Do Not Support Gang Box
Buzzer: Support
| Manufacturer | HIKVISION |
| Credential Type | 13.56MHz |
You will get an e-mail with parcel ID, once the goods are sent out
| up to 5 kg | 3,99 € | up to 10 kg | 5,00 € |
| up to 30 kg | 9,00 € | up to 75 kg | 15,00 € |
| up to 200 kg | 70,00 € | up to 1000 kg | 200,00 € |
