- Equipped with the 32-bit high-speed processor
- RS-485 and Wiegand (W26/W34) protocol, and OSDP protocol
- Build-in Mifare card reading module (Frequency: 13.56 MHz)
- Supports tampering alarm
- Built-in buzzer for identifying the reading status
- Online upgrade function
- Watchdog design for repairing itself in case that exception occurs, to ensure the long service life of the reader
Technical Information:
Processor - 32-bit
Tamper - support
RS-485 - support
Wiegand - support (set via DIP switch)
Card reading frequency - 13.56MHz
Card reading distance - ≤50 mm (≤1.97")
Indicator - Power indicator, status indicator
Power supply - 12 VDC
Power consumption - ≤2W
Working temperature - -20 °C to 65 °C (-4 °F to 149 °F)
Working humidity - 10% to 90% (Non Condensing)
Protective level - IP65
Dimensions - 115 mm × 44 mm × 22 mm (4.53'' × 1.73'' × 0.87'' )
Installation - Wall Mounting with Screws; Do Not Support Gang Box
Buzzer - support
| Manufacturer | HIKVISION |
| In stock | Yes |
| IP standard | IP65 |
