Supply voltage: 18 ÷ 40 V DC
Supply power: 12 W max.
Efficiency: 87 %
Output voltage: 12 VDC
Current consumption by converter systems: 10 mA max.
Output current tAMB<30 °C: 1 A - refer to chart 1.
Output current tAMB=40 °C: 0,7 A - refer to chart 1.
Ripple voltage: 100 mV p-p max.
Protection against short circuits (SCP) and overloads
(OLP): 200 % ÷ 400 % of module power – output power limit, automatic return after elimination of short circuit
IP protection class: IP67
Operating conditions temperature: -10°C ÷ 40°C, relative humidity 20 % - 90 %
Dimensions: (LxWxH) 50 x 48 x 25 [mm]
Net/gross weight: 0,10 kg / 0,13 kg
Length of DC input cable: 0,3 m
Length of DC output cable: 0,5 m + plug DC5,5/2,1 female
| Manufacturer | Pulsar |
| Charge (V) | 12V |
| Current (A) | 1A |
