| Approvals/certifications | Certified to EN54 Parts 11 & 16 by the LPCB. |
| Compatibility | Compatible with C-TEC's XFP/ZFP CAST Protocol Addressable Fire Panels. |
| Application/operation | Surface or flush mountable (supplied with a surface back box and flush mount adaptor plate for use in either application). |
| Supply/operating voltage | 27 to 40V DC. |
| Quiescent current | 370µA @ 35V DC. |
| Alarm current | 5mA. |
| Indicators | Red 'alarm ring'. Lit steady red (when activated) and flashing Red (when polling) |
| Connections | Loop IN, Loop OUT (x2). |
| Product dimensions (mm) | 87 W x 88 H x D 62mm (includes back box). |
| Construction & finish | Red ABS polycarbonate; Glass fibre window. |
| IP Rating | IP42. |
| Weight | 180g. |
| Operating conditions/temperature | -10ºC to +55ºC. |
| Manufacturer | C-TEC |
| In stock | Yes |
| IP standard | IP42 |
