Specification
- Speed min/max (s): 8/12
- From 7 to 9 m bar
- Protective rubber trim
- Indicator lights
- Strength and reliability: robust structure in steel, new high strength balancing springs guaranteed up to 1,000,000 opening and closing operations and elliptical section bar with high wind-gust resistance.
- Optional fl ashing or traffi c light can be integrated in cover.
- Encoder movement control and electromechanical limit switches.
- More comfort and safety in programming and maintenance phases: the separate enclosures for electronics and mechanics protect internal parts from potential risks.
- Rapid and easy access to the control unit located in the upper section of the barrier body.
- Simple fi xture of the completely concealed photocells onto the specially designed seats on the barrier body.
- More safety and reliability: obstacle detection and monitoring of motor absorption during automation movement.
- Automatic fault diagnostics during operation with consequent signalling of fault type through specifi c fl ash sequences.
- Provision for connection of latest generation optical and resistive sensitive edges (with 8.2 KOhm resistance).
- Energy saving: the system sets to standby when not in use to save consumption.
- No blackouts: emergency backup power with the optional batteries housed inside the case.
- Release from side with metal key, can be installed on either side.
| Parameters | Values |
| Absorption (mA) | 1300 |
| Work cycle (cycles/hour) | 150 |
| Torque (Nm) | 400 |
| Power (W) | 160 |
| Power supply | 230VAC; 24VDC |
| Protection rating (IP) | 54 |
| Working temp. (°C Min/Max) | -20/+50 |
| Weight (kg) | 98 |
| Dimensions (mm) | 500 x 299 x 1215 |
| Manufacturer | Nice |
| In stock | Yes |
| Current (A) | 1,3A |
| IP standard | IP54 |
| Power | 160W |
| Torque | 400Nm |
| Cycles per hour | 150 |
