- Operating Voltage 6V and 12V DC
- Reverse Polarity Protection Red LED Indication
- Max Input Voltage 15VDC
- Over Voltage Protection Max 30VDC (10 sec.) with Red LED Indication
- Battery Types SLA (AGM), GEL & Flooded (WET)
- Battery Sizes 6V (1.2Ah to 10Ah) and 12V (1.2Ah to 100Ah)
- AH Capacity Test Simulated 20 hour (C20) load test to 10.50VDC
- AH Calibration Calibrated at 0 (zero) position to brand new fully charged premium brand SLA batteries rated at C20 hour at 20°C (68°F)
- AH Result Based on the battery under test temperature and state of charge
- Adjustment Provides ± Ah adjustment to brand new fully charged standby SLA, cyclic GEL and car FLOODED lead acid batteries
- Battery Table Recharge or replace battery when Ah capacity available falls below 65% of the battery's stated capacity
- Display Type Blue Back-lit LCD
- Flat Battery Warning 6V <5.30VDC, 12V <10.50VDC
- Repeat Test Operation Can perform repeat tests continuously
- DCV Accuracy ±2% of displayed reading
- AH Accuracy ±5% Fully charged premium brand C20 hour rated SLA batteries at 20 - 25°C (68 - 77°F)
- Applied Pulsed Load 6A 1.2Ah - 7Ah, 18A 8Ah - 100Ah
- AH Calibration_ Adjustment Approx. ±25 dgts
- Case Construction High impact ABS with holster
- Dimensions 84(H) x 170(W) x 41(D)mm
| In stock | Yes |
Home delivery (recommended)
You will get an e-mail with parcel ID, once the goods are sent out
| up to 5 kg | 3,99 € | up to 10 kg | 5,00 € |
| up to 30 kg | 9,00 € | up to 75 kg | 15,00 € |
| up to 200 kg | 70,00 € | up to 1000 kg | 200,00 € |
